| Specification (mm²) | Cable outer diameter (mm) | Conductor outer diameter (mm) | Conductor Resistance at 20℃ (Max, Ω/km) | Insulation thickness (mm) |
Sheath thickness (mm) |
Rated voltage (V) |
|---|---|---|---|---|---|---|
| 3*0.2 | 5.2±0.2 | 1.3 | 92.3 | 0.4 | 1.0 | 300/300V |
| 3*0.3 | 5.5±0.2 | 1.5 | 69.2 | 0.5 | 1.1 | 300/300V |
| 3*0.5 | 6.1±0.2 | 1.8 | 39 | 0.5 | 1.1 | 300/300V |
| 3*0.75 | 7.2±0.2 | 2.2 | 26 | 0.6 | 1.1 | 300/500V |
| 3*1.0 | 7.8±0.2 | 2.4 | 19.5 | 0.6 | 1.2 | 300/500V |
| 3*1.5 | 8.6±0.2 | 2.8 | 13.3 | 0.7 | 1.2 | 300/500V |
| 3*2.5 | 10.4±0.2 | 3.4 | 7.98 | 0.8 | 1.3 | 300/500V |
| 3*6.0 | 14.9±0.2 | 5.2 | 3.65 | 0.9 | 1.8 | 300/500V |
