| Specification (mm²) | Conductor Structure (n/mm) | Insulation Thickness (mm) | Sheath thickness (mm) | Outer Diameter Lower Limit (mm) | Outer Diameter Upper Limit (mm) | Conductor Resistance at 20℃ (Max, Ω/km) | Insulation Resistance at 70℃ (Min, MΩ·km) | Current - Carrying Capacity Reference Value A |
|---|---|---|---|---|---|---|---|---|
| 2*0.12 | 7/0.15 | 0.4 | 0.6 | 3.3 | 4.3 | 158.0 | 0.016 | 1.4 |
| 2*.02 | 12/0.15 | 0.4 | 0.6 | 3.6 | 4.7 | 92.3 | 0.014 | 2.0 |
| 2*0.3 | 16/0.15 | 0.5 | 0.6 | 4.1 | 5.3 | 69.2 | 0.014 | 3.2 |
| 3*0.12 | 7/0.15 | 0.4 | 0.6 | 3.4 | 4.5 | 158.0 | 0.016 | 1.4 |
| 3*0.2 | 12/0.15 | 0.4 | 0.6 | 3.8 | 4.9 | 92.3 | 0.014 | 2.0 |
| 3*0.3 | 16/0.15 | 0.5 | 0.6 | 4.4 | 5.7 | 69.2 | 0.014 | 3.2 |
| 4*0.12 | 7/0.15 | 0.4 | 0.6 | 3.8 | 4.9 | 158.0 | 0.016 | 1.4 |
| 4*0.2 | 12/0.15 | 0.4 | 0.6 | 4.2 | 5.4 | 92.3 | 0.014 | 2.0 |
| 4*0.3 | 16/0.15 | 0.5 | 0.6 | 4.8 | 6.2 | 69.2 | 0.014 | 3.2 |
| 5*0.12 | 7/0.15 | 0.4 | 0.6 | 4.1 | 5.3 | 158.0 | 0.016 | 1.4 |
