| Specification (mm²) | Conductor Structure (n/mm) | Insulation Thickness (mm) | Outer Diameter Lower Limit (mm) | Outer Diameter Upper Limit (mm) | Conductor Resistance at 20℃ (Max, Ω/km) | Insulation Resistance at 70℃ (Min, MΩ·km) | Current - Carrying Capacity Reference Value A |
|---|---|---|---|---|---|---|---|
| 2×0.5 | 16/0.20 | 0.8 | 2.5×5.0 | 3.0×6.0 | 39.0 | 0.016 | 5 |
| 2×0.75 | 24/0.20 | 0.8 | 2.7×5.4 | 3.2×6.4 | 26.0 | 0.014 | 7 |
| 2×1.0 | 32/0.20 | 0.8 | 2.8×5.6 | 3.3×6.6 | 19.5 | 0.011 | 11 |
| 2×1.5 | 48/0.20 | 0.8 | 3.0×6.0 | 3.6×7.2 | 13.3 | 0.01 | 17 |
| 2×2.5 | 49/0.245 | 0.8 | 3.4×6.8 | 4.1×8.2 | 7.98 | 0.009 | 26 |
