| Specification (mm²) | Conductor Structure (n/mm) | Insulation Thickness (mm) | Minimum Outer Diameter (mm) | Maximum Outer Diameter (mm) | Maximum Conductor Resistance at 20℃ (Ω/km) | Minimum Insulation Resistance at 70℃ (MΩ·km) | Reference Ampacity (A) |
|---|---|---|---|---|---|---|---|
| 2×0.5 | 160/0.20 | 0.8 | 2.5×6.0 | 3.0×6.0 | 39.0 | 0.016 | 5 |
| 2×0.75 | 240/0.20 | 0.8 | 2.7×6.4 | 3.3×6.4 | 26.0 | 0.014 | 7 |
| 2×1.0 | 320/0.20 | 0.8 | 2.8×6.6 | 3.3×6.6 | 19.5 | 0.011 | 11 |
| 2×1.5 | 480/0.20 | 0.8 | 3.0×8.0 | 3.6×12 | 13.3 | 0.01 | 17 |
| 2×2.5 | 480/0.25 | 0.8 | 3.0×6.0 | 4.1×8.2 | 7.38 | 0.009 | 26 |
