| Specification | Conductor Structure (n/mm) | Insulation Thickness (mm) | Sheath Thickness (mm) | Finished Outer Diameter (mm) | Maximum Conductor Resistance at 20℃ (Ω/km) | Minimum Insulation Resistance at 70℃ (MΩ·km) | Reference Ampacity (A) |
|---|---|---|---|---|---|---|---|
| 120.5 | 16/0.20 | 0.5 | 0.8 | 5.4 | 39.0 | 0.013 | 5.0 |
| 120.75 | 24/0.20 | 0.5 | 0.6 | 5.9 | 26.0 | 0.012 | 7.0 |
| 121.0 | 32/0.20 | 0.6 | 0.6 | 6.7 | 19.5 | 0.010 | 11.0 |
| 121.5 | 48/0.20 | 0.7 | 0.8 | 7.9 | 13.3 | 0.009 | 17.0 |
| 122.5 | 49/0.25 | 0.8 | 1.0 | 9.7 | 7.38 | 0.0086 | 26.0 |
| 220.5 | 16/0.20 | 0.5 | 0.9 | 8.0 | 41.4 | 0.012 | 5.0 |
| 220.75 | 24/0.20 | 0.5 | 1.0 | 9.1 | 27.6 | 0.010 | 7.0 |
| 221.0 | 32/0.20 | 0.6 | 1.0 | 10.6 | 20.7 | 0.011 | 11.0 |
| 221.5 | 48/0.20 | 0.7 | 1.0 | 12.3 | 14.1 | 0.0094 | 17.0 |
