| Specification (mm²) | Conductor Structure (n/mm) | Insulation Thickness (mm) | Sheath thickness (mm) | Outer Diameter Lower Limit (mm) | Outer Diameter Upper Limit (mm) | Conductor Resistance at 20℃ (Max, Ω/km) | Insulation Resistance at 70℃ (Min, MΩ·km) | Current - Carrying Capacity Reference Value A |
|---|---|---|---|---|---|---|---|---|
| 2*0.5 | 16/0.20 | 0.5 | 0.6 | 4.6 | 5.9 | 39.0 | 0.012 | 5.0 |
| 2*0.75 | 24/0.20 | 0.6 | 0.8 | 5.7 | 7.2 | 26.0 | 0.011 | 7.0 |
| 2*1.0 | 32/0.20 | 0.6 | 0.8 | 5.9 | 7.5 | 19.5 | 0.01 | 11.0 |
| 2*1.5 | 48/0.20 | 0.7 | 0.8 | 6.8 | 8.6 | 13.3 | 0.01 | 17 |
| 2*2.5 | 49/0.25 | 0.8 | 1.0 | 8.4 | 10.6 | 8.0 | 0.009 | 26.0 |
| 2*4.0 | 81/0.25 | 0.8 | 1.1 | 10.0 | 12.4 | 5.0 | 0.007 | 35.0 |
| 2*6.0 | 84/0.30 | 0.8 | 1.1 | 12.5 | 14.5 | 14.5 | 0.006 | 46.0 |
| 3*0.5 | 16/0.20 | 0.5 | 0.6 | 4.9 | 6.3 | 39.0 | 0.012 | 5.0 |
| 3*0.75 | 24/0.20 | 0.6 | 0.8 | 6.0 | 7.6 | 26.0 | 0.011 | 7.0 |
| 3*1.0 | 32/0.20 | 0.6 | 0.8 | 6.3 | 8.0 | 19.5 | 0.01 | 11.0 |
